Servo HS 755MG

Hitec, 112756, Servo HS-755MG

Das neue Metallgetriebe-Servo für Anwendungen für Grossmodelle, sowohl Flugzeuge als auch Boote.

Technische Daten:
Gewicht:117.00 g
Lager/Bearing:2 Kugellager/Ball Bearing
Geschwindigkeit/Speed 4,8/6V (sec/60°):0.28/0.23
Drehmoment/Torque 4, 8/6V (Ncm):12/14.4
Standing Torque 4,8/6V (Ncm):96/115
Maß/Dimension (LxBxH):59x29x50
Gewicht/Weight (g):117
Motor:Eisenanker/Standard
Sonstiges/Misc:
Getriebe/Gear:Metall
Control System:+PULSE WIDTH CONTROL 1500usec NEUTRAL
Operating Voltage Range:4.8V TO 6.0V
Idle Current mA:8mA AT STOPPED
Running Current 4, 8/6V (mA/60°):230/250
Stall Current 4,8/6V (mA):1500/1800
Dead Band Width:5usec
Operating Travel:40°
Direction:CLOCK WISE/PULSE TRAVELING 1500 TO 1900usec
Potentiometer Type:6 SLIDER/INDIRECT DRIVE
Amplifier Type:Analog Amplifier
Horn Gear Spline:24 Segments / Ø 5.76
Splined Horns:Heavy Duty/HD-IL, HD-IS, HD-O,HD-LL,HD-LS
Connector Wire Legth:300mm
Connector Wire Strand Counter:60EA
Connector Wire Gauge:22AWG
