FX-30 + R6014 2.4 GHz - F8050
FASST Futaba Advanced Spread Spectrum Technology =
FX-30, new computer desk transmitter with 2.4 GHz FASST technology. The FASST system is a Spread Spectrum system with frequency hopping (FHSS). It may therefore transmit a maximum power of 100 mW EIRP, giving it ample reserves even for large-scale model aircraft and jets.
No crystals, no spot frequency selection, maximum security from same-channel interference.
Due to Spread Spectrum modulation, frequency hopping and encoding from transmitter to receiver using more than 130 million codes, almost trouble-free.
A detailed description of the FASST system benefits they see the FASST introduction page.
Easy programming with graphic menu system and large 255 x 96 pixel graphics LCD monitor and single-button operation using the 3-D hotkey. Comprehensive software provides also for functionally-oriented engine, glider and helicopter models, all necessary functions. Plenty of freely programmable mixers, with up to 17-point curves for setting up very complex mixer functions. Includes logical switched function for switches and sticks.
Menu and programming systems are identical with the T14MZ/FX-40 system. Model data can be interchanged using an SD card and using a conversion program with T12Z, T14MZ and FX-40 compatible.
The FASST system provides 14 channels with a resolution of 2048 steps. Due to the large bandwidth available to many channels are available with high resolution and fast signal (16.5 ms) are available. Virtually real-time control.
The corresponding R 6014 FS FASST receiver with diversity antenna system was advanced by BGA - layout technology (Ball Grid Array) on the dimensions of only 56.8 x 42.4 x 21 mm and a weight of 21g can be reduced.
Special precision dual-axis stick units with four double ball bearing with long life potentiometers and industry standard. Experience the new feeling of control. The stick units are designed for universal mode, and can the user from "throttle right" to "throttle left" to be changed.
The FX-30 transmitter features a new technology for the stick trims, namely rotary trims. This technique combines the advantages of traditional analogue trims with those of digital trims. With a movement direction and magnitude of the trim value can be set and saved automatically.
When the transmitter controls all controls are available. The order of the transmitter controls is freely selectable. The order of power outputs can be freely selected.
Internal 30-model memory, expandable with optional SD card 1 GB (1958 models). Software updates are also on SD card.
Technical data:
Dimensions: 205 x 220 x 55 mm
Weight: 1035 g
Channel spacing: 2048 kHz
Current consumption: 350
Power supply: 7.4 volts 3400 mAh Li-Po battery
Ü transmission system: 8-12 channel FM / PCM channel 10 1024 / 14 channel PCM 2048 (G3) / FSK
Functions: 28/14 Servos
more Specifications:
Delivery:
1 FX- 30
1x Transmitter Battery 7.4 V 3400 mAh LiPo
1x TM14 FASST RF module 2.4 GHz
1x R 6014 FS FASST receiver 2.4 GHz
1 Switch harness with charge socket
1 12 V Lithium battery charger (2)
1x 230 Volt SPS mains PSU for charging from mains
