Graupner GR-12S 2.4GHZ HoTT 6K receiver

Graupner GR-12S 2.4GHZ HoTT 6K receiver 33505

Item no.: G33505
EAN: 4013389456104

With GRAUPNER HoTT 2.4 GHz technology, the receiver features a new hopping telemetry transmission high-frequency section with state-of-the-art components and the latest software. A hardware antenna diversity always switches to the better antenna signal for reception and always uses the antenna that was last used for reception for transmission. This ensures that the return channel data is transmitted via the better positioned antenna. Without additional sensors, the receiver voltage, temperature and signal strength parameters are transmitted.

Features:
- The use of up to 75 channels ensures extreme operational reliability and is insensitive to external interference.
- The wide receiver voltage range of 3.6 V - 8.4 V (functional up to 2.5 V) ensures full functionality even with voltage fluctuations.
- Two LEDs signal the operating status.
- The size and weight have been reduced.
- The receiver input sensitivity and thus the range have been further increased.
- Servo connections on the front
- Failsafe, hold, OFF and standard (channel 1 failsafe, all others hold) programmable

Functions with SMART-BOX:
- 3 programmable mixers
- Linear, degressive and exponential programmable servo curves
- Programmable sum signal on channel 12 output
- Limitation and reversal of servo travel also possible in the receiver
- Failsafe, hold and OFF individually programmable for the servo channels
- Programmable warning thresholds for undervoltage, overtemperature and undertemperature
- Servo test function

HoTT- is the synthesis of expertise, engineering and worldwide testing by professional pilots. A 2.4 GHz system that points the way to the future of RC modelling.
HoTT- Hopping Telemetry Transmission is safety with up to 75 channels
HoTT- uses the frequency hopping spread spectrum technology. (FHSS)
HoTT- offers integrated telemetry in real time (expandable)
HoTT- is fully programmable using the Smartbox.

System features:
- Simple and extremely fast binding
- Range test and undervoltage warning function
- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)
- Failsafe, free channel assignment (channel mapping)
- Binding of any number of receivers for channel expansion (max. 32 channels)
- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (digital servos only!)
- Maximum interference immunity thanks to optimised frequency hopping and wide channel spread
- Extremely fast rebinding, even at maximum distance
- Telemetry evaluation in real time
- Future-proof thanks to update capability via USB interface
